LFH20 Smart Temperature and Humidity (MTI.AWS.LF.20) transducer is specially designed for indoor temperature and humidity detection. it is small in size, simple in installation and easy to operate. lt has special design for lightning surge, static electricity group pulse, withstand voltage, etc., and has strong anti-interference ability. There are three output modes of current voltage and RS485 to choose from. lt can be widely used in computer rooms, buildings, warehouses and other places where temperature and humidity are to be measured. Our LFH20 Temperature and humidity monitor can be applied in various fields including commercial buildings, industrial facilities, cleanrooms, data centers, healthcare, food and beverage, museums and archives, HVAC systems, greenhouse agriculture, and residential settings.
LFH20 Temperature Humidity Transmitter (Indoor)
Relative humidity
• Transducer: Digital
• Rang: 0%~100%
• Output: RS485/Modbus, 0~10VDC, 4-20mA optional
• Accuracy: ±3%@20°C&20-80%RH
• Response Time: ≤10s(20°C, slow flow air)
Temperature
• Transducer: Digital or thermal resistance, see Order Ref No.
• Range: 0~50°C, -20~60°C etc.
• Output: 4~20mA, 0~10VDC, RS485/Modbus optional.
• Thermal Resistance: See Order Ref No. and Thermal Resistance Index Table
• Accuracy: Digital type: ±0.3°C@20°C; Thermal resistance type: typical ±0.2~0.4°C@25°C, see Order Ref No.
• Power Supply: Voltage type/485 type: 15~35VDC/24VAC+20%(isolated power supply is required for AC power supply)
• Current type:19.5~35VDC(RL=500Ω)/9.5~35VDC(RL=0Ω)
• Output Load: ≤500Ω(Current type), ≥2KΩ(Voltage)
• Display: LCD display optional, with unit display and backlight
• Shell Material: PC housing
• Work Environment: -20~60°C, 5%-95%RH(Non-condensing)
• Protection Grade: IP30
• Electromagnetic Compatibility : EN61326-1
