Setting a new standard in UV irradiance monitoring, the MS-10S UVA and MS-11S UVB radiometers (MTI.AWS.EK.11S) with integrated transducers deliver precise temperature correction, outstanding stability, superior UV measurement range and unbeatable response times. Part of EKO’s elite S-Series range of solar monitoring solutions, the MS-10S and MS-11S also include a unique 4-channel smart interface compatible with 99% of data loggers, DAQ, and SCADA systems. And internal diagnostic sensors for remote visibility over internal temperature, humidity, tilt and roll angle, ensuring optimum performance with reduced maintenance costs. With a compact and lightweight design based on EKO’s universal sensor platform, the MS-10S and MS-11S are easy to manage, tough, reliable, and an industry-leading option for material testing, medical research and industrial field monitoring applications.
MS-11S UVB Radiometer
• Measurement Range: 0 to 10 W/m²
• Temperature Response (-20°C to +50°C): < ±1%
• Spectral Range: 280 to 315 nm
• Spectral Error: < 20%
• Directional Response (0° to 70°): < ±5%
• Response Time (95%): < 0.2 Sec
• Non-linearity: < 1%
• Operating Temperature Range: -40 to 80°C
• Output: Modbus 485 RTU, 4-20 mA, or 0-1 V (100 Ω)
• Power Consumption: < 0.2 W
• Size and Weight: ⌀96 x 101H, 0.4 kg
